Descriptions
OSCOO ON2000PRO M.2 2280 NVMe PCIe Gen5.0 SSD is a cutting-edge storage solution designed for those seeking extreme performance in a compact form factor. With its advanced PCIe 5.0 interface, it delivers unparalleled speed and responsiveness, setting new benchmarks in storage technology. It is a future-proof investment, ensuring top-tier performance for years to come as software and workloads become more demanding.
High speed and excellent user experience: Ultra fast storage experience, providing up to 14G/s performance, twice the performance of current mainstream Gen4 SSDs.
Safe data storage: Adopting independently developed 4K LDPC ECC technology, intelligent and flexible low-power error correction. Supports RAID protection to ensure data integrity and effectively extend product lifespan.
Advanced NAND flash memory management: Efficient garbage collection (GC) and bad decision management, reducing invalid data, optimizing hard drive operation, and improving performance, reliability, and lifespan. Fast TRIM algorithm, supporting dynamic management of Trim task load, further ensuring read and write performance. Static or dynamic wear leveling to minimize NAND aging to the greatest extent possible.

PCIe 5.0*4 NVMe 2.0 high-performance

Upgrade with full capacities up to 4TB

Compact M.2 2280 form factor

Low profile graphene aluminum heat spreader with fan and Independent cache



Specifications
Model Name | ON2000PRO |
Form Factor | M.2 2280 |
Interface | PCIe Gen5.0 x4, NVMe 2.0 |
NAND | 3D TLC |
Capacities | 1TB | 2TB | 4TB |
Independent Cache |
1TB - 1024MB 2TB - 2048MB 4TB - 4096MB |
Dimensions | 80(L) x 22(W) x 3.45(H)mm |
Weight | 8g |
Sequential Read/Write (Max.) |
1TB - 14000MB/s | 10000MB/s 2TB - 14000MB/s | 13000MB/s 4TB - 14000MB/s | 13000MB/s |
IOPS 4k Random Read/Write (Max.) |
1 TB - 1650K | 1800K 2 TB - 2100K | 1800K 4 TB - 2100K | 1700K |
TBW |
1TB - 700TB 2TB - 1400TB 4TB - 2800TB |
Encryption | TCG Opal 2.0, AES 128/256-bit Encryption |
Operating Temperature | 0˚C ~ 70˚C |
Storage Temperature | -40˚C ~ 85˚C |
Vibration | 10HZ ~ 2000HZ/20G |
Shock | 1500G/0.5ms |
MTBF | 1.5 Million Hours |
Operating System |
Windows 10/11 Mac OS 10.4 or later Linux 2.6.33 or later |
Warranty | 3 Years |
